Chevrolet Aveo Remove and Install Stereo and Speakers
	Chevrolet Aveo How to Remove, Replace and Install Car Stereo
	Factory Wire Color Codes See Diagrams Below
	Aftermarket Wire Color Codes See Diagrams Below
	Speaker Phasing Installing Aftermarket Speakers and Proper Hook-up
	NO AUDIO With aftermarket stereo installation?
	Erratic Volume Control DIY Repair
Chevrolet Aveo Front Speaker Removal and Replacement Chevrolet Aveo How to Remove and Install Front Speakers 1.1) Remove two screws along bottom edge of door panel. 2.1) Remove one screw along front of door panel. 3.1) Gently pry small cover from arm rest. 4.1) Remove exposed screw. 5.1) Gently pull top edge of small panel from door releasing clips. 6.1) Pull panel straight up to release bottom hook from behind door panel. 7.1) Roll window down and remember window handle position for installing. 8.1) There is a special tool for removing door handle clips. Most mechanics do not own one. There is a door handle and a small plastic washer. There are two other ways to attempt the removal. 9.1) Place a shop rag between door handle and washer. Pull shop rag up and down to wedge into opening. This may release the clip. 10.1) If you are unable to release the clip in the above step, here is a second way to remove. 11.1) Push the door panel in along with the washer, this will allow you to look down the edge of the door and see the clip. 12.1) With a pick tool, hook the door handle clip and pull to release. 13.1) Remove door handle and washer. Don't forget to install washer when reassembling. 14.1) Removed door handle and clip. 15.1) Immediately place clip onto door handle. Door handle can be snapped back onto shaft when reinstalling. Don't forget the original position of the handle. 16.1) Gently pry trim ring from door open handle. 17.1) Work your way around trim panel to release all clips. 18.1) Remove trim panel, look closely, this panel fits one way only. 19.1) Starting at bottom of door panel gently pry door panel from door releasing all clips. 19.2) Work your way up the front and back of door panel releasing remaining clips. 20.1) Lift back edge of door panel up out of window jam and over door lock pin. 20.2) Lift front edge of door panel up out of widow jam and remove panel. 21.1) Remove four screws securing speaker to door. 22.1) Check door for any door panel pins that were not removed with door panel. 22.2) Pry door panel pins from door. 23.1) Reinstall door panel pins to missing locations. 24.1) When reinstalling door panel, rubber grommet at door lock pin may pop off. Lift back edge of door panel up to reinstall and guide gently down over door lock. 25.1) Remember trim ring from door open handle, align and snap back into position.
Chevrolet Aveo Rear Speaker Removal and Replacement Chevrolet Aveo How to Remove and Install Rear Speakers 1.1) Open trunk for access. 1.2) Disconnect leads at both speakers. 2.1) Look for center brake light wire harness. 3.1) Release trigger on connector at center brake light. 4.1) Lower rear seat backs. 4.2) From rear deck, squeeze sides of cover at child seat lock downs. 5.1) Lift cover. 6.1) Remove bolt from child seat lock down. 7.1) Remove child seat lock down assembly. 8.1) Remove spacer. 8.2) Repeat for all child seat lock downs. 9.1) Gently pry under rear deck. 10.1) This will release clip without bending the plastic sides of the clip. 11.1) Repeat for all clips along the edge of the rear deck panel. 12.1) Gently lift center of rear deck panel up. 13.1) Release both sides of rear deck panel from behind edge of side panel. 14.1) Pull entire rear deck panel toward front seats. 15.1) Pull to allow access to rear deck speakers. Seat belt straps will remain in place. Lay rear deck down in place of upright rear seat backs. 16.1) Remove screws securing speakers to rear deck.
Wire Diagrams, Cadillac, Chevrolet, Corvette, Geo, GMC, Oldsmobile, Pontiac and Saturn. DO NOT CUT FACTORY WIRE HARNESS     Aftermarket stereo installation? Why purchase the aftermarket wire harness? Installation is easier, no guess work with wire color codes and a Headache Saver! Factory wire colors codes are not universal. See Aftermarket Videos above. We discourage cutting the factory wire harness. This section aids in troubleshooting and determining wire color codes, phasing for speaker hook up, locating power wires for installing external devices and add-ons. Diagrams may not be applicable to Bose Audio Systems     1978 - 1992 IMPORTANT - There are two (2) yellow*, two (2) gray and two (2) brown wires in this harness. Locate the +12 volt constant wire first. Label it or splice to constant wire on aftermarket stereo first. Swapping yellow wires will cause damage to any aftermarket stereo. Check fuses if your unable to find +12 volts. 1   Black Ground 2   Gray Dimmer 3   or Blank Antenna/Amplifier Trigger On 4   Yellow Switched +12 volts 5   Light Green Right Front Speaker (+) 6   Tan Left Front Speaker (+) 7   Gray Left Front Speaker (-) 8   Dark Green Right Front Speaker (-) 9   Brown Left Rear Speaker (+) 10   Dark Blue Right Rear Speaker (+) 11   Light Blue Right Rear Speaker (-) 12   Yellow Left Rear Speaker (-)     Factory Wire Harness On Factory Car Stereo   13     Orange Orange Constant +12 Volts 14     Brown Brown Illumination Corvette Only with Second One Wire Black Connector 15       Pink Bose Amplifier Trigger On     1988 - 2005 IMPORTANT - There are two (2) yellow*, two (2) gray and two (2) brown wires in this harness. Locate the +12 volt constant wire first. Label it or splice to constant wire on aftermarket stereo first. Swapping yellow wires will cause damage to any aftermarket stereo. Check fuses if your unable to find +12 volts. 1   Gray Left Front Speaker (-) 2   Tan Left Front Speaker (+) 3   Dark Green Right Front Speaker (-) 4   Light Green Right Front Speaker (+) 5   Black Ground 6   Brown Illumination 7   Gray Dimmer 8   Blank   9   Yellow* (Green) Switched +12 volts 10   Orange Constant +12 volts 11   Light Blue Right Rear Speaker (-) 12   Dark Blue Right Rear Speaker (+) 13   Yellow Left Rear Speaker (-) 14   Brown Left Rear Speaker (+)     Wire Codes and Pin Lay Out on Back of Factory Car Stereo Note the location of the connector "Keys" in yellow.   1 Ground 2 Right Front Speaker (+) 3 Right Front Speaker (-) 4 Left Rear Speaker (-) 5 Left Rear Speaker (+) 6   7   8   9   10   11   12   13 Illumination 14 Right Rear Speaker (+) 15 Right Rear Speaker (-) 16 Left Rear Speaker (-) 17 Left Rear Speaker (+) 18   19   20   21 Dimmer 22   23 Switched +12 Volts 24 Constant +12 Volts     All wire diagrams and color codes are not 100% accurate.
